Product Details

Specifications

Decoding

• Decoding Format - Ultra 265, H.265, H.264
• Decoding Capability - 1 x 8MP@30, 2 x 5MP@25, 3 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30
• Decoding Capability Description - The resolution of each channel cannot exceed 3840 pixels in length and 2160 pixels in width
• Audio Compression - G.711A, G.711U

Network

• Incoming Bandwidth - 64 Mbps
• Outgoing Bandwidth - 48 Mbps
• Max Users Can Be Added - 32
• Remote Users - 128
• Protocols - TCP/IP, P2P, SMTP, RTSP, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, IPv4
• Browser (Plugin) - IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

Video/Audio Input

• IP Video Input - 8-ch

Video/Audio Output

• Video Output - Support 1-ch HDMI, 1-ch VGA, HDMI and VGA simultaneous output
• HDMI Output - 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
• VGA Output - 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
• HDMI Standard - HDMI2.0
• 3.5mm Audio Output - 1-ch
• Liveview Display - 1/4/6/8/9
• Default Num of Live Screen - 9
• Corridor Mode Screen - 3/4/5/7/9
• Playback Screen - 1/4/9

Two-way Audio

• Two-way Audio - N/A

Snapshot

• FTP/Schedule/Event Snapshot - 1-ch snapshot (max. D1 (720 × 576) video resolution, with D1 snapshot resolution)

Recording

• Recording Resolution - 8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF
• Num of Concurrent Playback - 16-ch
• Synchronous Playback in Local - 8-ch

Smart

• VCA Detection by IPC - Face Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD)
• VCA Search - Face Snapshot Search, Behavior Search
• Smart by IPC - Total 4-ch(Face Detection, SIP, UMD)
• Capacity of Snapshot Records - 2 millions records for SIP

Alarm

• General Alarm - Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Audio Detection
• Alert Alarm - IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

• GUI Language - 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian

Hard Disk

• SATA - 1 SATA Interface
• Capacity - Up to 10 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size)

External Interface

• Network Interface - 1 RJ45 10 M/100 M self-adaptive Ethernet Interface
• USB - Rear panel: 2 × USB2.0
• Buzzer - Support
• Power Supply - DC 12 V/2 A

WiFi

• Frequency - 2.4 GHz
• Transmission Rate - 150 Mbps
• Wireless Standards - IEEE 802.11b/g/n, IEEE 802.11ax

Working Environment

• Working Temperature - 14 ℉ to 131 ℉ (-10 ℃ to 55 ℃)
• Working Humidity - ≤ 90% RH (non-condensing)
• Power Consumption (without HDD) - <12W
• Heat Dissipation - Radiator

Dimensions

• Weight (without HDD) - 1.32lb (≤0.6Kg)
• Height - 1U
• Dimensions - 205mmx205mmx45.6mm

Certification

• Certification - CE; FCC; UL; RoHS; WEEE
• CE - EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130
• FCC - Part15 Subpart B

Camera Specifications

• Max Resolution - 2 MP
• Sensor - 1/3.0" CMOS
• Min. Illumination - Colour: 0.01 lux (F2.0 AGC ON), 0 lux with IR on
• Day/Night - IR-cut filter with auto switch (ICR)
• Shutter - Auto/Manual, 1 to 1/100000 s
• Adjustment Angle - Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360°
• S/N - > 52 dB
• WDR - DWDR

Lens

• Focal Length - 2.8 mm
• Iris Type - Fixed
• Iris - F2.0
• Field of View (H) - 94.0°
• Field of View (V) - 52.4°
• Field of View (D) - 106.5°
• Lens Type - Fixed

DORI

• DORI Distance (Lens) - 2.8mm
• DORI Distance (Detect) - 46.7m(153.1ft)
• DORI Distance (Observe) - 18.7m(61.2ft)
• DORI Distance (Recognize) - 9.3m(30.6ft)
• DORI Distance (Identify) - 4.7m(15.3ft)

Illuminator

• Supplemental Light - IR
• Illumination Distance (IR) - 98.4 ft (30 m)
• Wavelength - 850 nm
• IR On/Off Control - Auto/Manual

Video

• Video Compression - Ultra 265, H.265, H.264
• H.264 Code Profile - Baseline profile, Main profile, High profile
• Frame Rate
  • Main Stream: - 25fps @ 1080P (1920x1080), 25fps @ 720P (1280x720)
  • Sub Stream - 25fps @ 640x360, 25fps @ 2CIF(704x288), 25fps @ CIF(352x288)
• Video Bit Rate - 128 Kbps to 2048 Kbps
• U-code - Support
• OSD - Up to 2 OSDs
• Privacy Mask - Support (only NVR)
• ROI - Up to 8 areas
• Video Stream - Dual Streams


• White Balance - Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2
• Digital Noise Reduction - 2D/3D DNR
• Smart IR - Support
• Flip - Normal, Flip Vertical, Flip Horizontal, 180°
• Dewarping - N/A
• HLC - N/A
• BLC - Support
• Defog - Digital Defog

Events

• Basic Detection - Motion Detection, Ultra Motion Detection
• General Function - IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication

Audio

• Audio Compression - G.711U, G.711A
• Audio Bitrate - 64 Kbps
• Two-way Audio - N/A
• Suppression - Support
• Sampling Rate - 8 kHz

Storage

• Edge Storage - Micro SD, up to 512 GB
• Network Storage - ANR

Network

• Protocols - IPv4, TCP, UDP, DHCP, RTSP, DNS, DDNS, NTP, HTTP
• Compatible Integration - API, SDK
• User/Host - Up to 32 users. 2 user levels: administrator and common user
• Security - Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2
• Client - EZStation, UNV-Link, UNV-Link Pro
• Web Browser - Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+

Wi-Fi

• Wireless Standards - IEEE802.11b/g/n/ax
• Frequency Range - 2.4 GHz to 2.4835 GHz
• Channel Bandwidth - 20/40 MHz Support
• Modulation Mode - 802.11b: CCK 802.11g/n: OFDM 802.11ax: OFDMA
• Wi-Fi Security - 64/128-bit WEP, WPA-PSK/WPA2-PSK
• Transmit Power - 802.11b: 17±1.5 dBm@11 Mbps802.11g: 16±1.5 dBm@54 Mbps802.11n: 16±1.5 dBm@MCS7802.11ax: 16±1.5 dBm@MCS9
• Receive Sensitivity - 802.11b: -76 dBm@11 Mbps (Typical)802.11g: -65 dBm@54Mbps (Typical)802.11n: -61 dBm@MCS7, HT40 (Typical)802.11ax: -54 dBm@MCS9, HE40 (Typical)
• Transmission Rate - 802.11b: 11 Mbps802.11g: 54 Mbps802.11n: up to 150 Mbps802.11ax: up to 270 Mbps

Interface

• Built-in Mic - Support
• Built-in Speaker - N/A
• WIFI - Support
• Network - 1 × RJ45 10 M/100 M Base-TX Ethernet
• Video Output - N/A

Certification

• EMC - CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130) FCC (FCC 47 CFR part15 B)
• RF - FCC ID (FCC CFR 47 part15 C)CE RED (EN 301 489-1, EN 301 489-17, EN 300 328, EN 62311)
• Safety - CE LVD (EN 62368-1)
• Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU);
• Protection - IP67 (IEC 60529)

General

• Power - DC 12V±25%
• Power Consumption - Max 3.5W
• Power Interface - Ø5.5 mm coaxial power plug
• Dimensions - 6.3” × 3.0” × 2.8” (160 × 76 ×72 mm) (L x W x H)
• Weight - 0.55 lb (0.25 kg)
• Material - Metal + Plastic
• Storage Environment - -22 ℉ to 140 ℉ (-30 ℃ to 60 ℃), Humidity: ≤ 95% RH (non-condensing)
• Working Environment - -22 ℉ to 140 ℉ (-30 ℃ to 60 ℃), Humidity: ≤ 95% RH (non-condensing)
• LED Indicator - 1, red/green
• Surge Protection - 4 KV
• Reset Button - Support
• Web Client Language - 1 Language: English
